32
＜ BeforeUse ＞
ŦƒƑƑƈƆƗƒƕŃƉƒƕŃƗƕƄƌƑƈƕŃƉƘƑƆƗƌƒƑ
When you use the trainer function, connect the
optional trainer cable between the transmitters for
teacher and student.
*You can set the trainer function on the Trainer Function
screen in the System menu.
ŦƒƑƑƈƆƗƒƕŒųƏƘƊ
WARNING
Donotconnectanyotherchargers
exceptthespecialchargertothis
chargingconnector.
*IfyoutakeouttheLiFebatteryFT2F2100BV2from
thetransmitter,youcanusetheoptionalbalance
chargerLBC-4E5correspondingtoLiFebattery.
ŦƒƑƑƈƆƗƒƕŃƉƒƕŃƅƄƗƗƈƕƜŃƆƋƄƕƊƈƕ
This is the connector for charging the LiFe
battery FT2F2100BV2 that is installed in the
transmitter. Do not use any other chargers except
the attached special charger corresponding to LiFe
battery.
Rubbercover
Trainer
Connector
S.BUS (S.I/F)
Connector
Charge
Plug
Earphone
Plug
ŶőťŸŶŃƆƒƑƑƈƆƗƒƕŃŋŶőŬŒũŌ
When using an S.BUS servo and telemetry
sensor, connect them both here.
ŨƄƕƓƋƒƑƈŃƓƏƘƊ
Connecting a stereo headphone to this plug, the
speech information of telemetry can be heard.
