FUTABA T6K-V2 - Throttle Curve

108
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe+
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
1AIL 2AIL1AIL1FLP 2AIL1FLP ELEVONWINGTYPE
However,thisfunctioncannotbeusedwhenthethrottleEXPfunctionwasset.Whenthisfunctionisset,
thethrottleEXPfunctioncannotbeused.
This function sets a 5 point throttle curve so that
the engine/motor speed relative to movement of the
WKURWWOHVWLFNLVWKHRSWLPXPYDOXHIRUÀLJKW
ŏ$FXUYHFDQEHVHWIRUHDFKVZLWFKSRVLWLRQ
"THRCRV"
THRCRV
Throttlecurve
(AIRPLANE)
■ Activatingthefunction
＋ −
or
①Selectthe"MIX"item
andthenselectthe
"ON"bypressingthe+
keyor‒key.
● Whenyoudonotuseafunction,settothe
"INH"side.
■ Switchselection
＋ −
or
②Selectthe"SW"item
andthenselectthe
switchbypressingthe
+keyor‒key.
Range：SwA-SwDDefault：SwC
■ 5pointcurveset
＋ −
or
③ByJogkey,eitherofP-1toP-5ischosen.The+keyor-keyispressedanda
rateissetup.
Range：0-100%
Default：P-1:0%,P-2:25%,P-3:50%,P-4:75%,P-5:100%
Throttlecurve
Activatingthefunction
Switchselection
5pointcurve
set
● Selectthesettingitem
withtheJogkey.
● Whennotusingthisfunction,
selectINH.
● Theset-upcurveisshown
（Presentswitchposition）
