FUTABA T6K-V2 - Model Type Selection (MDL TYP)

55
Commonfunction
Function
MDLTYP
Modeltype
(Common)
Six swash types are available for helicopters.
Five types of main wings and two types of tail
wings are available for airplanes and gliders.
Functions and mixing functions necessary for each
model type are set in advance at the factory.
Note: The Model Type function automatically
selects the appropriate output channels,
control functions, and mixing functions for the
chosen model type.
When the Model Type selection command
is accessed, all of the data in the active
memory is cleared (except the following
swash type.) Be sure that you don’t mind
losing this data, or back it up to another
memory using the copying functions.
（WINGTYPE:GLIDER）
Aileron1
(CH1)
Aileron6
(CH6)
2AIL
Aileron１Servo
(CH1)
1AIL1FLP
(CH5)
Aileron１Servo
(CH1)
1AIL
Aileron1
(CH1)
Aileron6
(CH6)
2AIL2FLP
Flap3
(CH3)
*2AIL2FLPtypecan'tbeusedfora
motorglider.
（WINGTYPE:AIRPLANE）
（TAILTYPE）
NORMAL Ｖ-TAIL
Elevator
+Rudder
(CH4)
Elevator
+Rudder
(CH2)
Elevator
(CH2)
Rudder
(CH4)
Aileron１Servo
(CH1)
1AIL
Elevon1
(CH1)
Elevon2
(CH2)
ELEVON
Aileron1
(CH1)
Aileron6
(CH6)
2AIL
Flap１Servo
(CH5)
2AIL1FLP
Aileron１Servo
(CH1)
Flap１Servo
(CH5)
1AIL1FLP
(CH5)
Aileron1
(CH1)
Aileron6
(CH6)
Flap１Servo
2AIL1FLP
Flap5
(CH5)
Flap１Servo
(SWSHTYPE:HELICOPTER)
$,/
(/(
3,7
؟$LOHURQ6HUYR
؟(OHYDWRU6HUYR
؟3LWFK6HUYR
(Normallinkagetype)
H-1:eachservolinked
totheswashplate
independently.
