FUTABA T6K-V2 - EXT-Voltage Alarm Set up

81
Commonfunction
ThissettingwillsoundanalarmwhentheEXT-voltagedropsdangerouslylow.VIB(vibration)that
vibratesthetransmitteratthesametimecanalsobeset.
Method
① Select"EXT-VOLT"fromtheteleme-
tryscreenwiththeJogkey.
②Openthesettingscreenby
pressingtheJogkey.
① IntheEXT-VOLTscreenstate,select
(ALARM)fromthemenuwiththe
Jogkey.
② Selectthe"ACT"bypressing
the+keyor‒key.
① IntheEXT-VOLTscreenstate,se-
lect(LIMIT)fromthemenuwith
theJogkey.
②Selectthe voltageby
pressingthe+keyor‒
key.
Selectionrange：
0.0V-70.0V
● Whenyouwanttoset5.0V,pressthe
+keyand‒keysimultaneously.
① IntheEXT-VOLTscreenstate,select
(VIB)fromthemenuwiththeJog
key.
②Selectthe"TYP1-TYP3"by
pressingthe+keyor‒key.
Callingthesettingscreen
Alarmset
Alarmvoltageset
Vibrationset
● EXT-Voltagealarmsetup
＋ −
or
＋ −
or
＋ −
or
TYPE1
TYPE2
TYPE3
"VIB"types
Ifthefollowingtypesareselected,the
transmitterwillvibrateduringthewarning.
DN(down)showsthanan
alarmisgeneratedwhen
thevoltagedropsbelow
thesetvoltage.
