FUTABA T6K-V2 - Telemetry Functions (TLMTRY)

75
Commonfunction
Function
①Callthemenuscreenfromthe
homescreenbypressingthe+key
for1second.
＋
② Select
fromthemenuwiththeJog
key.
③Openthesettingscreenby
pressingtheJogkey.
Callingthesettingscreen
TLMTRY
Telemetry
(Common)
This screen displays and sets the various information from the receiver. An alarm and vibration can be
generated depending on the information. For example, a drop in the voltage of the receiver battery housed
in the aircraft can be reported by an alarm.
● ThisfunctioncanonlybeusedintheT-FHSSAirmode.TheS-FHSSsystemcannotusetelemetry.
● Telemetrysensorssoldseparatelycanbemountedintheaircrafttodisplayavarietyofinformation.(Receivervoltage
doesnotrequireasensor.)
● ThetelemetryfunctioncannotbeusedifthetelemetrymodeoftheparametersisnotACT.
● When2receiversareusedwith1transmitter,thetelemetryfunctioncannotbeused.
Intheinitialstate,thereceivervoltageisdisplayedatthetransmitter.
Display
● Viewingthereceivervoltage.
RX-BATT
Viewingthereceivervoltage. Settingisunnecessary.Whenmenutelemetryis
listenedto,thevoltageappears.
Viewingthedrivebattery
voltage.
R3008SB,CA-RVIN-700andwiringworkare
necessary.
Usingvariousoptional
telemetrysensors.
Optionaltelemetrysensorsarenecessary.T6K
settingisunnecessary.
Settingalarmsfromthe
telemetryinformation.
Settingby"Telemetry"inthemenuisnecessary.
P.75
P.79
P.83
P.84-90
● Howtodisplayreceivervoltage
onahomescreen.
PARAMETER
HOME-DSP
"RXBATT"ischosenby ＋keyor− key.
"TLMTRY"
Receivervoltagedisplay
（1second）
HOME → → SERVOmonitor → → TELEMETRYdisplay
ENDkeypressedreturntoHOME.
− −
