FUTABA T6K-V2 - Swash AFR (SWH AFR)

129
Helicopter
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe+
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
This is the adjustable function rate (AFR) func-
tion when HR3, H-3, HE3, HN3 or H-2 is selected
as the swash type. The ailerons, elevators, and pitch
steering angle and direction can be adjusted.
"SWHAFR"
（WhenswashtypeisH-1,thissettingscreenisnotdisplayed.）
■ Traveladjustmentofeachfunction
＋ −
or
①Selecteachfunctionitemof"RATE"and
settheratebypressingthe+keyor‒
key.
Range：-100to+100%
Default：+50%
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
SwashAFR
● Selectthesettingitem
withtheJogkey.
Rete
● Dependingontheswashtypethe
screendisplayisdifferent.
● Whenthepolarityischanged,the
directionofoperationisreversed.
NOTE：Ifthesteeringangleistoolarge,linkagebindingmayoccur.
SWHAFR
SwashAFR
(HELICOPTER)
