5.3 FLITECHARTS
®
WARNING: Do not use the approach information provided by the VFR
navigation database residing within the GPSMAP 695/696 as a means of
navigating any instrument approach. The GPSMAP 695/696 VFR navigation
database is limited to present only the waypoints for the final approach leg of
a published procedure. These waypoints and associated course line are made
available for monitoring purposes only.
FliteCharts
®
resemble the paper version of National Aeronautical Charting Office
(NACO) terminal procedures charts. The charts are displayed with high-resolution and
in color for applicable charts. FliteCharts
®
database subscription is available from
Garmin. Available data includes:
•Arrivals(STAR)
•DepartureProcedures(DP)
•Approaches
•AirportDiagrams
•TakeoffMinimums
•AlternateMinimums
The geo-referenced aircraft position is indicated by an aircraft symbol displayed on
the chart when the current position is within the boundaries of the chart. An aircraft
symbol may be displayed within an off-scale area depicted on some charts.
The figure below shows examples of off-scale areas, indicated by the grey shading.
Note, these areas are not shaded on the published chart. These off-scale areas appear
on the chart to convey supplemental information. However, the depicted geographical
position of this information, as it relates to the chart planview, is not the actual
geographic position. Therefore, when the aircraft symbol appears within one of these
areas, the aircraft position indicated is relative to the chart planview, not to the off-
scale area.
