TRAFFIC WARNING WINDOW
The system displays the Traffic Warning Window when the GDL 39 issues a traffic
advisory (TA). The Traffic Warning Window is a small pop-up map in the lower left
corner. The Range Rings on the pop-up alert are spaced every whole mile/kilometer/
nautical mile. Press the CLR Key to remove the Traffic Warning Window.
DISPLAYING TRAFFIC DATA
Traffic is displayed by default on the Map Page and in the Traffic Warning Window.
Traffic Symbol and Traffic Label (i.e., relative altitude, altitude trend and absolute
motion vectors) settings selects the maximum range at which traffic labels or symbols
are shown. Traffic Labels can also be turned off.
Enabling/disabling traffic data on the Map Page:
1) Press the TRAFFIC Softkey.
Or:
1) From the Map Page, press the MENU Key.
2) Turn or move the FMS Joystick to highlight ‘Set Up Map’, and press the
ENT Key.
3) If necessary, turn the FMS Joystick to highlight the ‘Traffic’ Category from
the horizontal list.
4) Move the FMS Joystick to highlight ‘Traffic Data’.
5) Turn the FMS Joystick to select ‘ON/OFF’ and press the ENT Key.
Customizing traffic data on the Map Page:
1) From the Map Page, press the MENU Key.
2) Turn or move the FMS Joystick to highlight ‘Set Up Map’, and press the
ENT Key.
3) If necessary, turn the FMS Joystick to highlight the ‘Traffic’ Category from
the horizontal list.
4) Move the FMS Joystick to highlight ‘Traffic Symbol’, or ‘Traffic Label’ field.
5) Turn the FMS Joystick to select ‘OFF’, ‘AUTO’ or range settings for Traffic
Symbol and Traffic Label, and press the ENT Key.
