AIRSPACE SYMBOLS
Item Symbol
Class B, Class E,
CTA
Class A, Class C,
TMA
Class D
Mode C Veil
TRSA
MOA
Danger, Alert, or
Training Area
Restricted,
Prohibited, or
Warning Area
Radar Area
ATZ, TIZ
MATZ
ADIZ
Misc/Unknown
VFR Americas/Pacific Database
Item Symbol
Class B, Class E,
CTA
Class A, Class C,
TMA, TRSA
Class D
MOA
Danger, Alert, or
Training Area
Restricted,
Prohibited, or
Warning Area
Radar Area
ATZ, TIZ
Misc/Unknown
IFR Americas/Pacific Database
