RX II Series User Manual
Illustrator Plug-In A-5
The system will create the 4 marks as shown in the picture below.
Note:
1. To save your materials, in addition to amending object margins, you can also adjust the
length of the registration marks (5mm minimum) when you apply 4-Point Positioning (see
table 1 for suggestions based on different material sizes). The smaller the size is, the
smaller the distance between the object and the registration marks is (see the figures
below).
To Next Page
