AFR-24S User Manual
58
Step 7 Unscrew the Cut-off Blade from the Cut-off Blade Fixer, which will be attracted by the
magnet on it, and replace it with a new Cut-off Blade along the track highlighted in red using
tweezers (Figure 2-45 and 2-46).
Note: The Cut-off Blade is sharp so please handle with care.
Screw
Old Cut-off Blade
New Cut-off Blade
Figure 2-44
Figure 2-43
Figure 2-45
Figure 2-46
Magnet
