CorelDRAW Example (Page Setup and Orientation)
The following is an example of how to set the Page Setup and Orientation in the graphics
software. CorelDRAW is the designated graphics software used for this example. For other
graphics software, you will need to access the corresponding Page Setup page.
1) From the primary menu, click LAYOUT → PAGE SETUP.
2) From the navigation bar on the left, click DOCUMENT → PAGE → SIZE.
3) Ensure that NORMAL PAPER and LANDSCAPE are selected.
4) Ensure the Paper Width and Height dimensions match the LaserPro S400 work area
dimensions
S400: 880x610 mm (34.6”x20”)
5) Click OK to end the paper size adjustment.
T i p
Instead of manually selecting the Landscape and setting the Paper Width and
Height, you can simply click the Set From Printer function and CorelDRAW
will automatically set the proper orientation and dimensions based on LaserPro
S400’ work table. (You MUST have the S400 set as the default printer prior to
doing this.)
5.2.2 Color Management
The LaserPro driver uses pen color settings to control laser engraver’s engraving and cutting
parameters. In addition to having your Page Setup and Orientation properly set in your
graphics software, you will a o need to make sure Color Management is DISABLED prior to
working with the LaserPro S400 Print Driver.
From your graphic software’s Color Management page:
• Disable Color Management or set Color Management to Off.
CorelDRAW Example (Color Management)
The following is an example of how to properly disable Color Management in the graphics
software. CorelDRAW is the designated graphics software used for this example. For other
graphics software, you will need to access the corresponding Color Management page.
1) From the primary menu, click TOOL → COLOR MANAGEMENT and CorelDRAW’s Color
Management will appear.
2) Under the Style pull down menu, select COLOR MANAGEMENT OFF.
3) Click OK to complete the color management adjustments.
