137 232003110G (03)
Rotary Fixture (Paper Page) [DEFAULT SETTING: Unselected]
This option is only to be used with the Rotary Attachment optional accessory properly
set up. For instructions on how to set up the Rotary Attachment, please refer to
Chapter VII of this manual.
You will need to select this option when processing a job with the optional rotary attachment
system to engrave on round or cylindrical objects. When you have your material and rotary
attachment properly set up:
1) Check the Rotary Fixture function and notice the change in the Paper Size fields under Paper
Size, the X value represents the length of your work piece. Enter the length of your work piece
in this field.
2) Under Paper Size, the Diameter value represents the diameter of your working piece (at the
position you wish to engrave). Enter the diameter of your work piece in this field. Again,
remember the proper diameter value would be the diameter location, at the point of engraving
on your work piece.
3) Under Rotary Parameter, the Offset value represents distance from the open end of your work
piece to the base of the padded rubber wheel. This value will be displayed on the LCD panel.
Enter the proper offset value in this field.
Roll to Roll Autofeeder* (Paper Page) [DEFAULT SETTING: Unselected]
This option is only to be used with the Roll to Roll Autofeeder optional accessory properly set up.
The Roll to Roll Autofeeder function is allow laser system to work with roll media continuously,
when laser machine finishes the work, the Roll to Roll Autofeeder will automatically to wind up the
processed material and load another frame of unprocessed material for laser processing.
For instructions on how to set up and operate the Roll to Roll Autofeeder, please refer to its
accessory manual along its package.
CCD* (Paper Page) [DEFAULT SETTING: Unselected]
This option is only to be used with the CCD optional accessory properly set up. The CCD optional
module allow you to laser contour cut the printed image, the CCD module will find the registration
marks printed around the image, and position the laser contour cutting line automatically. For
instructions on how to operate the CCD, please refer to its manual along with package.
1. This option is only to be used with the CCD optional accessory properly set up.
2. When activate CCD selection in print driver, the paper size will be reduced.
5.2.3.5 S400 Print Driver >> Language Page
This page allows you to specify the language displayed by the S400 Print Driver. Current
language options allow for: English, Spanish, French, Chinese (Simplified, Traditional),
Japanese, and German. Remember to select “Save to Default” on Options Page to save the
specified language.
