GCC Technologies LaserPro S400 - Laserpro S400 Specification Sheet

195 232003110G (03)
10.2 LaserPro S400 Specification Sheet
Work Area
40 x 24 in. (1016 x 610 mm)
Max. Part Size
(W x L x H)
All doors closed
41.4 x 25.4 x 11 in. (1053 x 647 x 280mm)
All doors open
41.4 x ∞ x 11 in. (1053 x ∞ x 280 mm)
Table Size
Standard Grid Cutting Table 40.1 x 24.1 in. (1019 x 613 mm)
Dimensions (W x L x H)
56.7 x 34.5 x 41.3 in. (1440 x 900 x 1048 mm)
Weight
CO2 30W~40W
260 kg / 573 lb
CO2 60~100W
270 kg/ 595 lb
Laser Source
10.6-μm CO2 laser: 30 to 100W
9.3-μm CO2 laser: 60W
Fiber laser: 20W, 30W, 50W, 60W
Cooling
Air-cooled, Operating environment temperature 15°- 30°C (59°-
86°F)
Drive
Closed-loop DC servo control
Maximum Motor Speed
140 IPS
Speed Control
Adjustable from 0.1~100% (Up to 16 color-linked speed settings
per job)
Power Control
Adjustable from 0~100% (Up to 16 color-linked power settings
per job)
Engraving Capability
256-level gray scale image processing capability
Distance Accuracy
0.254 mm or 0.1% of move, whichever is greater
Z-Axis Movement
Automatic
Focus Lens
Standard 2"
Resolution (DPI)
Available 125, 250, 300, 380, 500, 600, 760, 1000, 1500
Computer Interface
10 Base-T Ethernet, Full speed 2.0 USB
Compatible Operating System
MS Windows 64 Bit
