184 232003110G (03)
Anytime you have the SmartLID open, always make sure you have properly engaged the
SmartLID manual locks on both sides of the metal support rai . Failure to do so may pose
a serious risk if the SmartLID slams down.
Closing the SmartLID:
To properly close the SmartLID after you have finished accessing the work table or motion
system, please follow these steps:
1) Disengage both of the sliding locks found on each side of the metal support rai by sliding
them away from you and into the unlock position.
2) Push the SmartLID away from you and move to the maximum position to disengage the latch
(indicated by a small click) and gently close the SmartLID.
8.2.2 Cleaning the Work Table and Motion System
Clean the working table and the motion system on a frequent basis through the following steps:
1) Turn the power off and unplug the S400 before cleaning.
2) Use a vacuum cleaner with a flexible nozzle to remove dust and debris from the work table
and motion system.
3) Apply small amounts of all-purpose cleaner, alcohol, or acetone to a paper or cotton towel to
clean the working table.
4) Apply a soap solution, all-purpose cleaner, or alcohol to a paper or cotton towel to wipe
down the rai of the motion system.
5) Wait for all cleaning residue to dry completely before plugging in and operating the S400.
• Never pour or spray alcohol or acetone directly to the work table.
• Oil, alcohol and acetone can cause fires or smoke build-up if improperly used.
T
i
p
Please clean the AutoFocus pin each time after completing the engraved job
to make sure the AutoFocus pin is free to move.
8.2.3 Lubrication of the X & Y Axis
In order to keep the motion system running smoothly, the X and Y axis of the motion system will
need lubrication on weekly base. Apply 0.1ml of lubrication syringe in accessory box to the X
liner rail of S400 mode on bi-week base, while apply a small amount of light grade machine oil
or PS2 grease to a paper or cotton towel and apply to the X rail of S400 model, and Y axis of
S400. You can purchase PS2 grease from NSK dealers worldwide. Please visit
http://www.nsk.com/eng/company/network/index.html
for additional information
• Clean and lubricate the X linear rail of S400 with 0.1ml grease from syringe every
month to properly maintain the motion system.
The lubrication oil for the X linear rail on S400 must to be ordered from GCC
LaserPro and its authorized dealers. Other unknown grease may damage the
rail’s life time and performance.
