179 232003110G (03)
OPERATION MENU:
After optional SmartGUARD hardware installation, please enter the function menu on the Touch
Screen to enable the SmartGUARD fire alarm. Note SmartGUARD fire alarm system is not a fire
extinguisher, but an fire detecting and alarm system.
SmartGUARD
Enable
/
Disable:
Press directional key (Left or Right) to enable the SmartGUARD device or disable it.
Sensitivity
：
Press directional key (left or right) to set the sensitivity of SmartGUARD. There are five sensitivity
settings (1, 3, 5, 7, 9 seconds) that can be selected. Sensitivity defines the delay time from when a
fire is detected until the fire alarm alerts user, and automatically stop laser firing. For example, if
the sensor delay switch is set to the 3-second position, the SmartGUARD will start an alarm and
automatically stop laser firing after detecting a fire for 3 seconds.
Stow Carriage
：
This function will decide if the lens carriage stay in the last position (set to <NO>) or move to the
opposite direction (up or down) when fire alarm is initiated. The default is <YES>, the lens carriage
will move to opposite direction when a fire detected.
Select<
Ad
v
a
n
c
e
d
O
p
t
i
on
s
>from the menu
Select<S
m
a
r
t
GU
A
RD>
from the menu
