Carriage / Work Table Adjustment Page
The Carriage / Work Table Adjustment Page allow you to manually increase and decrease the
height of the work table (Z-axis). In addition, you can manually adjust the Y-axis and X-axis of
the lens carriage.
Carriage / Work Table Adjustment Page
Manually decrease the height of the work table (Z-axis)
Manually increase the height of the work table (Z-axis)
Manually adjust the Y-axis position of the lens carriage
Manually adjust the X-axis position of the lens carriage
To Next Page
