Chapter 2: Front panel programming
110 Vigilant VS1 and VS2 Technical Reference Manual
To program CMS devices:
1. Display the panel configuration options menu. See
“Panel programming” on page 103.
2. Choose CMS Device.
3. Choose the device you want to program.
4. Program each device and option using Table 29 on
page 108. For dialer options, see Table 30 below. For
receiver options, see Table 31 on page 113.
5. After programming each device option, choose Save.
6. Press the Menu button to exit menu mode, or
continue programming.
Panel Configuration
Ann. Class
Annunciator
CMS Device
⇩
CMS Device
Dialer
Network
Swngr Shtdn
Rp.200<>
⇩
CMS Device
Swngr Shtdn
Rp.200<>
Event Notification
Save
Dialer programming
The dialer has a number of options that can be programmed. The dialer can be used
as a dialer for sending event information to the central monitoring station, and it can
be used as a modem for dial-in programming and status and report retrieval.
Table 30: Dialer programming options
Option Description
Type Set the dialer type to:
Dual line: Uses LINE 1 and LINE 2 to transmit events to the central
station receiver and performs modem functions.
Single line: Uses LINE 1 only to transmit events to the central
station receiver and performs modem functions.
Modem only: Dialer provides interface for outbound
communications and the ability for dial-in programming and status
and report retrieval. Note: If Modem Only is selected, only Rings to
Answer, Ring Type, and Callback Number can be programmed. No
other dialer options are displayed in the menu. The modem
function only works with LINE 1.
None: No dialer is installed or if a dialer is installed, disables the
dialer.
Account 1 and 2
Account ID:
Primary receiver number:
Program account 1 options, and then program account 2 options.
When you have finished programming each account, choose Save.
Enter account 1 and 2’s four-digit ID code. FFFF is not valid.
Enter the primary receiver’s phone number. This can contain up to
20 digits (0-9, *, #, and ,). The comma causes a two-second delay in
dialing. The number or hash symbol (#) and the asterisk symbol (*)
are used with calling feature codes and services. Consult your
telephone service provider.
