Troubleshooting: Diagnostic Control Screen
Diagnostic Control Screen
The Diagnostic Control screen, as shown below, is used to perform the following
diagnostic self-tests:
Recorder Calibration test;
Status Relay softkey tests Nurse Call Interface relay;
CPU software version number;
DSP software version number;
Monitor Run Time;
Recorder run time (Rec Time);
Clear softkey sets run time and record to 0:00
Main Board SW1 switch setting summary;
Softkey to access J102 test screen; and
Softkey to access the NIBP Calibration screen.
Diagnostic Control
J102
Exit
Diagnostic Control
Recorder Calibration: Off
Status Relay: Off
NIBP Cal
CPU V4.30 X DSP 03.07
Clear
Run Time:
Rec Time:
SW1: 10111110
MECG MSpO
2 NIBP
366:29:49
0:18:11
To Next Page
