Revision D 250 Series Maternal/Fetal Monitor 6-5
2020551-001
Parts List, Drawings, and Replacement: Field-Replaceable Units (FRUs)
9 1 2025177-022 Plastic Bezel w/cables DRU Depot repair only, do not ship
to FE. Customers out of
warranty may purchase
9 2-4 2025177-023 Keypad/Volume Pad FRU
9 7,8 2025177-026 Trim Knob and Switch
10 1 2025177-017 Recorder Assembly w/o Mnt Brkt FRU
11 25 2025177-018 Recorder Board FRU
N/A N/A 2025177-002 Hardware Kit FRU Screws, washers, spacers for
full monitor
N/A N/A 2025177-031 Top Cover Gasket FRU Refer to Caution on page 6-30
Serv. Manual
Drawing Page
Number
Bubble
Number
Part Number Description Comments
