Product icons
LOGIQ e – Basic Service Manual 1-17
5461614-100 English Rev. 6
INMETRO Certification: TUV
Rheinland Brazil
Rating plate Note: Only
after Brazilian regulatory
registration is complete,
this label will be located
on the console rating
plate.
Disconnect the probe connector
of Three-Probe Port before
remove the system from
Docking Cart Platform,
otherwise the probe cable will
be damaged.
Docking Cart Top Cover
Guidance on how to connect the
system to the docking cart and
how to release it.
When put the system on
docking cart top cover, avoid
injuring the fingers and hands.
Make sure the system’s handle
is locked well after mounting the
system to docking cart top
cover. When connecting the
probe connector to the system,
press the probe connector
locking lever up. When
releasing the system from the
docking cart, disconnect the
probe connector of Three-Probe
Port from the system before
lifting up the system.
Docking Cart Top Cover
Do not disconnect the probe
connector of Three-probe Port
from the system when the
system is in use.
Probe Connector of
Three-Probe Port
Table 1-5: Product Icons (Continued)
Label/Icon Purpose/Meaning Location
To Next Page
