GE MAC 1200 ST Operator's Manual

8-16 MAC 1200/1200 ST Revision C
2012250-021
Stress Tests: Ergometers with Remote Start Pulse
When pressed while the test is on hold in the EXERCISE phase,
the EXERCISE phase restarts.In stage 2 of the PRE EXERCISE
phase, this button advances to the EXERCISE phase.
In the exercise phase, this button advances to the post-
exercise phase.In the post-exercise phase, this button is
pressed for the first time when all electrodes have been
reapplied. After that, it can be pressed to initiate additional
median beat reports
In the exercise phase, this button stops the Master steps
(“stage hold”). When pressed again, the test continues. While
on hold, the stage counter stops.
The Master Step Test (Default Protocol)
Alt
Phase Stage Name Duration of Stage
Advancing to
Next Stage
Reports
PRE-
EXERCISE
1 SUPINE until baseline ST is available automatic 12-lead report at beginning stage
report at end
2 ELECTR. OFF until button is pressed with button NO
EXERCISE 1 STEPPING 90, 180, or 270 seconds automatic NO
POST-
EXERCISE
1
POST-EX1
1
1. In the POST-EXERCISE phase, the message ELECTR. ON is displayed instead of the stage name to prompt the user to reapply
the ECG electrodes. The stage name reappears, when the user, having applied the electrodes, presses .
3 minutes automatic stage report
2 POST-EX2 2 minutes automatic stage report
3 POST-EX3 2 minutes automatic stage report
4 POST-EX4 2 minutes automatic stage report
5 POST-EX5 2 minutes automatic stage report
6 POST-EX6 2 minutes automatic stage report
7 POST-EX7 2 minutes automatic stage report
8 POST-EX8 2 minutes automatic stage report
9 POST-EX9 2 minutes automatic stage report
10 POST-EX10 2 minutes automatic stage report
