Revision C MAC 1200/1200 ST 10-3
2012250-021
System Setup: General Information
General Information
Press to display the configuration menu.
The main menu with the following options will appear.
Operating mode: Automatic (Manual, Arrhythmia, Stress Test)
System Setup
Communication
Patient Data Setup
Option Code
At “Operating mode”, you will always see the currently selected mode. So
be sure to select the appropriate mode before entering the configuration
menu.
To access the menu options, position the bar cursor on the option
with the cursor keys and confirm the selection with .
The operating steps to select a setting are always the same.
Using the cursor keys and , you select the setting and
confirm the selection with .
The cursor will move to the next menu item.
Individual items can be skipped with or .
To exit the menu, press .
The factory default setting is shown in angular brackets [...].
System Setup Keys
<
M
>
Arrhy
Pat
mm/mV
045A
To Next Page
