10-4 MAC 1200/1200 ST Revision C
2012250-021
System Setup: Automatic Mode
Automatic Mode
Use the cursor keys to position the bar cursor on Automatic and confirm
the selection with .
The configuration menu for the Automatic mode will appear.
Report Sequence
[STANDARD] (I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6)
CABRERA (aVL, I, -aVR, II, aVF, III, V1, V2, V3, V4, V5, V6)
NEHB (I, II, III, aVR, aVL, aVF, D, A, J, D, A, J) (only measured with
the HEART interpretation program)
Rhythm Leads
Depending on the selected report format, the recorder will print 0, 1, 3 or
6 selectable rhythm leads.
With the 12_F1 report format, the printed rhythm lead is V6 (for NEHB
leads: lead J), with formats 3_F1, 6_FS, and 6_F1, the first (selected)
rhythm lead, with formats 1x10R3 and 4x2.5R3 the first 3, and with
formats H1 and A1 all 6 rhythm leads.
Gain
5, [10], 20, 40 mm/mV, *auto
Report Format
Refer to Chapter 5, “Report Formats” section.
Detailed Results (MAC 1200 / 1200 ST Only)
The Detailed results page will be printed, yes/[no] (Chapter 5, “Report
Formats” section).
