10-32 MAC 1200/1200 ST Revision C
2012250-021
System Setup: ECG Transmission via Modem
ECG Transmission via Modem
Select the Automatic mode and press .
Press to display the configuration menu for Automatic mode.
Use the cursor keys to position the bar cursor on Manual copy to
HOST and confirm the selection with ([HOST]).
Press to clear the configuration menu.
Use the cursor keys to position the bar cursor on Communication and
confirm the selection with .
Selecting the Communication Protocol
This adjustment is only necessary with MAC 1200/1200 ST units,
because only these devices can send data to CardioSys/CardioSoft or to
MUSE. For MAC 1100 units that can send data only to CardioSys/
CardioSoft, the communication protocol A5 is preselected.
Use the cursor keys to position the bar cursor on Protocol. Select the
protocol A5 if you will send data to CardioSys/CardioSoft, or select
CSI to send data to MUSE.
Use the cursor keys to position the bar cursor on Modem, other and
confirm the selection with .
Choose the modem you use from the list and confirm the selection
with .
If your modem is not included in the list, select other and enter the
required modem commands (see Chapter 5, “Modem Setup (for
Modem Æ Other)” section).
When you have selected a standard modem, position the bar cursor
on Dial mode and select the appropriate mode.
Enter the telephone number of the receiving modem and the number
to access the public telephone network and terminate the
configuration with .
