Revision C MAC 1200/1200 ST 5-13
2012250-021
Automatic Mode Recording: ECG Transmission
Then it sends batch of ECG records.
3. After the transmission, a message on the display indicates the
number of successfully transmitted ECGs. As soon as you
acknowledge the message with , the Automatic mode acquisition
screen appears.
Transmission Log
The MAC 1200/1200 ST unit can be set up to automatically print a log of
the recently completed transmission. See “Transmission Log” on page 10-
25 for more information.
If the Transmission log is enabled, after each record is transmitted, the
message Print transmission log? will display.
Press to print the log.
The message Printing Transmission Log displays as the log is printing.
Error Messages
Transmission error messages are listed below.
ECG transmission error! (A5)/(CSI)
(depending on selected protocol)
Check interface!
Dial locked! (temporarily) No dial tone!
Busy! No answer!
No carrier! Check modem configuration!
