10-26 MAC 1200/1200 ST Revision C
2012250-021
System Setup: Communication
Communication
Baud Rate (PC)
Transmission rate for the selected protocol. We recommend the default
setting of [19200 baud].
Protocol
The recorder offers two communication protocols: “A5” and “CSI” (Client
Server Interface, MAC 1200 / 1200 ST only).
With the “A5” protocol, the 10-second resting ECG can be transmitted to
CardioSys and CardioSoft.
The CSI protocol supports the transfer of resting ECGs from the
electrocardiograph to a MUSE CV system.
Modem
Select the modem type. Choose among the standard modems MultiTech
(MT 19.2, 56k), Elsa 14.4, 28.8, 33.6, 56k and a user-defined modem.
When using one of the standard modems, enter is the following:
The dial mode (pulse or tone, depending on your telephone network).
The telephone number (20 digits maximum).
The number to access the public telephone network (e.g. “0”).
For a user-defined modem, enter the following:
The telephone number (20 digits maximum).
The init string (20 characters maximum). (See modem operator's
manual.)
The dial string (20 characters maximum). (See modem operator's
manual.)
The hangup mode (20 characters maximum). (See modem operator's
manual.)
