Revision C MAC 1200/1200 ST 5-23
2012250-021
Automatic Mode Recording: Adjusting Measurement Points/QT Dispersion
Local T Offset Measurement Point/QT Dispersion
When you exit the screen for verification of the global measurement
points, the screen for verification of the T offset measurement point
appears automatically.
Verification of the T Offset Measurement Point
Therefore, this screen always shows only one lead at a time and the T
offset point. Changing the local T offset point also affects the QT
dispersion value.
Description
1 Amplitude in [mV]
2 Selected lead
3 Time in [s]
4 Active marker
1 mV
1 s
029A
12 3 4
