GE MAC 1200 ST Operator's Manual

Revision C MAC 1200/1200 ST 10-11
2012250-021
System Setup: Arrhythmia Mode
Arrhythmia Mode
Use the cursor keys to position the bar cursor on Arrhythmia and confirm
the selection with .
The configuration menu for the Arrhythmia mode will appear.
Report Sequence
STD_C: V1, V2, V3, V4, V5, V6
STD_RED: I, II, III, V2, V4, V6
STD_LI: I, II, III, aVR, aVL, aVF
CABR_LI: aVL, I, -aVR, II, aVF, III
NEHB: I, II, III, D, A, J
HIGH_C: V1’, V2’, V3’, V4’, V5’, V6’4 (you can configure a custom
sequence with these leads):
 Position the cursor on HIGH_C.
 Press and create the report sequence as described in “Manual
Mode” section.
Gain
The unit will automatically determine the gain setting (*auto, 5, [10], 20,
40 mm/mV; with “*auto”).
Muscle Filter
Elimination of muscle artifact: yes, [no].
AC Filter
Elimination of AC line interference: [yes], no.
