Manual Mode Recording: Recording
Recording
127(
In Manual mode, messages indicating disconnected electrodes are
also annotated on the recording, e.g. Lead fail C1.
After switching on the unit, press to select Manual mode.
Before recording the ECG, patient data can be entered ( ). It is
recommended that you enter the patient’s name to annotate it on
every report.
Before initiating a recording, check the display for error messages (see
table below). Check all electrodes; if the message persists, there must
be a break in the patient cable. Replace the cable with a new one.
The recording is started and stopped with .
Table 2. Messages Indicating Disconnected Electrodes
*R*: Right arm electrode disconnected
*L*: Left arm electrode disconnected
*F*: Left leg electrode disconnected
*C1*: Chest electrode C1 disconnected
*C2*: Chest electrode C2 disconnected
*C3*: Chest electrode C3 disconnected
*C4*: Chest electrode C4 disconnected
*C5*: Chest electrode C5 disconnected
*C6*: Chest electrode C6 disconnected
*NA*: Nehb electrode Nap disconnected
*NT*: Nehb electrode Nst disconnected
*NX*: Nehb electrode Nax disconnected
