3-4 MAC 1200/1200 ST Revision C
2012250-021
Operating and Performance Tests: Installation and Mains Connection
Installation and Mains Connection
The figure below shows a practical arrangement of patient and recorder.
For interference-free operation, it is important that the patient cable and
the power cord do not run parallel.
Arranging the Electrocardiograph and the Examination Couch
Use the power cord to connect the device to the power line (see figure
below). Use only the original power cord or an equivalent cable.
AC Power Input
Indicator 2 will illuminate.
Check the paper supply (the window in the paper door allows you to
look inside the paper compartment). Refer to Chapter 10, “System
Setup” for instructions on inserting a new paper pad.
