Revision C MAC 1200/1200 ST 4-13
2012250-021
Preparing for ECG Recording: Entering Patient Data
New Patient
Yes: existing patient data are deleted.
No: entered data can be edited.
Last Name, First Name
18 characters each
Date of Birth
You do not need to enter separators between date, month, and year
fields.
The button has the function of the Shift-Lock key when entering
data in alphanumeric text boxes. This function allows you to enter the
characters shown in the upper part of the keys, without pressing the
Shift key. The symbol appears in the display to indicate the Shift-
Lock status.
Patient ID
This field accepts 3 to 16 characters. The exact length is determined in
the patient data setup menu.
127(
When entering a patient ID which consists of numerals only, the
blanks preceding the number are replaced with 0. Example: If a 6-
digit text box is configured and you enter the patient ID 123, the final
ID number will read “000123”. The default value for this field is 9
characters.
Prompt 1 No
Prompt 2 No
Prompt 3 No
Prompt 4 No
1. with 12SL program only
Table 1. Patient Data Entry Menu
Parameter
Factory Default
Options
Adjusted Menu Item Displayed
