Revision C MAC 1200/1200 ST 14-3
2012250-021
Technical Specifications: Recording
Recording
Direct recording of waveforms and alphanumeric characters with
rectangular coordinates by means of thermal-array printhead printing
on thermosensitive paper.
3 or 6 recording channels, or 12 in Automatic mode, overlapping
Baseline pitch:
6 channels: 31 mm (manual)
12 channels: 16 mm (automatically)
Writing width 200 mm maximum
Annotation of recorder settings, date, time and entered patient name
in the margin of the recording strip.
With appropriate software, documentation of analysis results in the
respective operating mode.
Resolution of the recording:
Vertical 8 dots/mm
Horizontal 25 µm at 25 mm/s
Printer Paper
CONTRAST
®
/ ARCHIVIST
®
Z-fold pad, 150 pages per pad, equivalent
to a chart length of approximately 45 m
Paper width: 210 mm or 8.5 inch (215.9 mm; US format)
Sheet length: 297 mm or 11 inch (279.4 mm; US format)
To prevent damage to the printhead use only the original CONTRAST
®
/
ARCHIVIST
®
paper.
Paper Transport
Paper speed
5-25-50 mm/s, key selectable
Error limits at 25 and 50 mm/s, typical ±l%
at 5 mm/s, ±10% max.
At paper end, the recorder emits an audio signal and stops recording.
The last pages of the pad bear a colored stripe in the lower margin.
