5-14 MAC 1200/1200 ST Revision C
2012250-021
Automatic Mode Recording: ECG Transmission
Transmission to a CardioSys/CardioSoft System via Modem
Depending on the modem model used, the modem MUST be connected
either with the 9-pole cable 223 378 01 or with the 25-pole cable 223 378
02.
For transmission of the ECG, the unit must be set up as described in
Chapter 10, “ECG Transmission via Modem” .
1. After acquiring the ECG, start the transmission with .
The MAC 1200/1200 ST is also capable of transmitting stored ECGs
(if memory option MEMO is installed).
Activate the storage program by simultaneously pressing and
. (Press the button first and hold it depressed.)
2. To select one or more ECGs for transfer, move the cursor down with
.
When the cursor reaches Print directory, it moves on to the patient
list. In the list, the bar cursor changes to a line cursor.
To select multiple ECGs, select them with , while holding
down. Selected ECGs are marked with a black bar in the margin
of the display. Deselect ECGs with the same key combination.
3. When you have selected the ECG(s) to transfer, press . You will
be returned to the function key menu.
4. Using the cursor, select the Send command. Confirm your choice
with .
The transmission menu will be displayed, showing the phone number
and the options Start transmission, Modify settings, and Cancel.
5. Check the displayed telephone number and press to initiate the
transfer.
If it is necessary to change the number, press to display the
configuration menu.
