Revision C MAC 1200/1200 ST 5-7
2012250-021
Automatic Mode Recording: Recording
MAC 1200 with the MEMO (memory) option
ECGs are not automatically stored (configurable)
ECGs that were successfully transmitted to a host system are not
automatically removed from memory (configurable)
QTC is calculated with the Bazett formula (only MAC 1200 with option
MEAS (measurement) or DIAG (measurement + interpretation)).
The locations of all relevant device settings are shown below:
The display shows three leads at a time. With you can display all
leads of the report sequence in groups of three.
The recording can be stopped with .
For a description of the different reports, see “Report Formats” on
page 5-10.
Operating mode Muscle filter
1
1. if enabled
AC line filter
1
Anti-drift system
1
“Patient Name”
Report function
2
2. or REC OFF when the recording function is disabled
Gain Report sequence
Three leads
display here
Failure message
3
3. if any
Heart rate
