Revision C MAC 1200/1200 ST 5-9
2012250-021
Automatic Mode Recording: The Storage Program
127(
Due to the limited size of the display, you cannot view the entire
list at a time. These are the columns that follow to the right of
the patient name:
Date and time of the ECG recording
S (indicates that the ECG has been sent to another system)
Patient ID
Comments
To display the remaining columns, you can continuously scroll
the display with or you can shift the list by the display’s
width with and .
3. When you have selected all ECGs to view, press the key to
return to the function keys.
4. Use the cursor to select the function you need. Initiate it with .
Other Considerations
With the Print directory command, you can print a list of all stored
ECGs. The printout includes all columns, except the Comments column.
If you try to save an ECG when the memory is full, a message informs
you of the memory status. When you delete an ECG from memory, the
new ECG will automatically be saved.
The unit may be set up to automatically save ECGs (without pressing
) and automatically remove ECGs from memory that were
successfully transmitted to the CardioSys, CardioSoft or MUSE systems.
The storage program can be terminated at any time with .
127(
If you plan to print a large number of stored ECGs, connect the unit
to the power line or to check that the battery is fully charged.
When you terminate the storage program with , it is not
possible to save the current ECG again.
