6-6 MAC 1200/1200 ST Revision C
2012250-021
Manual Mode Recording: Recording
The locations of all relevant device settings are shown below:
If you change the writer speed, lead group or any filter settings
during a recording, the unit will briefly stop.
With you advance to the next group of 6 leads of the selected
report sequence.
When the anti-drift system is enabled, there will be a short delay of
2.2 seconds before the recording starts.
The heart rate limit is automatically calculated from the date of birth
(WHO 100% = 220 - age). When the date of birth is not entered, the unit
will set the limit at 180 bpm. This value can be changed with and
(in steps of 5 bpm).
Operating mode Muscle filter
1
1. if enabled
AC line filter
1
Anti-drift system
1
“Patient Name”
Report function
2
2. or REC OFF when the recording function is disabled
Gain Report sequence
Three leads
display here
Failure message
3
3. if any
Heart rate
