Appendix B -Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
This column contains general system settings
Language 00 01 English
English
Francais
Deutsch
Espanol
The default language used by the device. Selectable as English, French, German, Spanish.
Password 00 02
4 registers for writing 8 character password
Each register contains a pair of characters
Each register is formatted as follows:-
first character of a pair
second character of a pair
Each character is in the Courier range 33 - 122
Plain text password entry cell
Sys Fn Links 00 03 0
Trip led self reset
[Binary Flag (1) Indexed String]
Setting to allow the fixed function trip LED to be self resetting (set to 1 to extinguish the LED after a period of healthy restoration of load
current).
Description 00 04 MiCOM P54x
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
16 character relay description. Can be edited.
Plant Reference 00 05 MiCOM
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Associated plant description and can be edited.
Model Number 00 06 Model Number
Model Number
[ASCII Text (32)]
Relay model number. This display cannot be altered.
Serial Number 00 08 Serial Number
Serial Number
[ASCII Text (7)]
Relay model number. This display cannot be altered.
Frequency 00 09 50
50 or 60
[Unsigned Integer (16 bits)]
Relay set frequency. Settable either 50 or 60 Hz
Comms Level 00 0A 1
Comms Level
[Unsigned Integer (16 bits)]
Displays the conformance of the relay to the Courier Level 2 comms.
Relay Address 00 0B 255
From 0 to 255 in steps of 1
[Unsigned Integer (16 bits)]
Sets the first rear port relay address.
Plant Status 00 0C
Plant Status
[Binary Flag (16)]
Displays the circuit breaker plant status.
Control Status 00 0D
Control Status
[Binary Flag (16)]
Active Group 00 0E
Active Group
[Unsigned Integer (16 bits)]
Displays the active settings group
CB Trip/Close 00 10 No Operation
No Operation
Trip
Close
No Operation
No Operation
No Operation
No Operation
No Operation
No Operation
