Appendix B -Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Close CB2
[Indexed String]
Supports trip and close commands if enabled in the Circuit Breaker Control menu.
CB Trip/Close 00 10 No Operation
Trip
Close
No Operation
No Operation
No Operation
No Operation
No Operation
No Operation
Trip CB2
Close CB2
Supports trip and close commands if enabled in the Circuit Breaker Control menu.
Software Ref. 1 00 11
Software Ref. 1
[ASCII Text (16)]
Displays the relay software version including protocol and relay model.
Opto I/P Status 00 20
[Binary Flag (32)
Display the status of the available opto inputs fitted.
Relay O/P Status 00 21
[Binary Flag (32)
Displays the status of all available output relays fitted.
Alarm Status 1 00 22
Setting Group via opto invalid
Test Mode Enabled
Static Test Mode
Loop Back Test Enabled
IM64 Test Enabled
VTS Indication
CTS Alarm
CT2S Alarm
Remote CTS Alarm
Power Swing
BF Block AR
CB Monitor Alarm
CB Lockout Alarm
CB Status Alarm
CB Failed to Trip
CB Failed to Close
Control CB Unhealthy
Control No Checksync
Autoclose Lockout/RLY BAR
No Healthy (AR)
No Check Sync / AR Fail
System Split Alarm
GPS Alarm
Signaling failure alarm
Signaling Propagation Delay Alarm
Differential protection failure alarm
IM64 Scheme Fail alarm
IEEE C37.94 Communications Alarms
Diff Protection inhibited
Aid1 Channel Out
Aid2 Channel Out
Frequency out of range
[Binary Flag (32)
Displays the status of the first 32 alarms as a binary string. Includes fixed and user settable alarms. Data type G96
