GE MiCOM P40

P446SV
Appendix B -Settings and Signals
P446SV-TM-EN-1
B91
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Blocking Timer 25 04 5
From 1 to 30 in steps of 1
[Unsigned Integer (16 bits)]
Front Port 25 05 Enabled
Disabled
Enabled
[Indexed String]
Rear Port 1 25 06 Enabled
Disabled
Enabled
[Indexed String]
Rear Port 2 25 07 Enabled
Disabled
Enabled
[Indexed String]
Ethernet Port 25 08 Enabled
Disabled
Enabled
[Indexed String]
Courier Tunnel 25 09 Enabled
Disabled
Enabled
[Indexed String]
IEC61850 25 0A Enabled
Disabled
Enabled
[Indexed String]
DNP3 OE 25 0B Enabled
Disabled
Enabled
[Indexed String]
Attempts Remain 25 11
Attempts Remain
[Integer]
Blk Time Remain 25 12
Blk Time Remain
[Integer]
Fallbck PW Level 25 20 0
Fallbck PW Level
[Unsigned Integer (16 bits)]
Security Code 25 FF
Security Code
[ASCII Text]
CTRL I/P LABELS
29
00
This column contains settings for Control Input Labels
Control Input 1 29 01 Control Input 1
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Setting to allow Control Inputs 1 set/ reset.
Control Input 2 29 02 Control Input 2
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Setting to allow Control Inputs 2 set/ reset.
Control Input 3 29 03 Control Input 3
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Setting to allow Control Inputs 3 set/ reset.
Control Input 4 29 04 Control Input 4
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Setting to allow Control Inputs 4 set/ reset.
Control Input 5 29 05 Control Input 5
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
