Chapter 2. CPU Features & Specifications

92 PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual GFK-2222AD

Error Checking and Correction, IC698CRE020

Redundancy CPUs are shipped with error checking and correction (ECC) enabled. Enabling ECC results in

slightly slower system performance, primarily during power-up, because it uses an extra eight bits that

must be initialized. If you upgrade the firmware on the non-redundancy CPU model IC698CPE020 to

support redundancy, you must set the ECC jumper to the enabled state as described in the installation

instructions provided with the upgrade kit.

The CRE020 performance measurements provided in Appendix A were taken with ECC enabled.

For details on ECC, refer to the PACSystems Hot Standby CPU Redundancy User Manual, GFK-2308.
