Chapter 5
.
C
ommunicat
ions
GFK
-2222AD
April 2018
197
5.2.6
Serial Port Bau
d Rates
Protocol
COM1
(RS
-
232)
COM2
(RS
-
485)
Station Mgr
(COM3)
(RS
-
232)
RTU Slave
1200, 2400, 4800,
9600, 19.2K, 38.
4K,
57.6K, 115.2K
1200, 2400, 4800,
9600, 19.2K,
38.4K, 57.6K,
115.2K
not supported
Firmware
Upgrade via
WinLoader
1200, 2400, 4800,
9600, 19.2K, 38.
4K,
57.6K, 115.2K
Not supported
not supported
Message Mode
1200, 2400, 4800,
9600, 19.2K, 38.
4K,
57.6K, 115.2K
1200, 2400, 4800,
9600, 19.2K,
38.4K, 57.6K,
115.2K
not supported
SNP Slave
1200, 2400, 4800,
9600, 19.2K, 38.
4K,
57.6K, 115.2K
1200, 2400, 4800,
9600, 19.2K,
38.4K, 57.6K,
115.2K
not supported
Serial I/O
1200, 2400, 4800,
9600, 19.2K, 38.
4K,
57.6K, 115.2K
1200, 2400, 4800,
9600, 19.2K,
38.4K, 57.6K,
115
.2K
not supported
207
209
