Chapter 2
.
CPU Features
& Specifications
GFK
-2222AD
April 2018
63
Switches CPE330
Figure
19
: CPE330
RUN/STOP Switch and
RDSD Switches
The RDSD and RUN/STOP
Switches ar
e located behind
the
protective door
, as shown in Fig
ure
19
.
Refer to
RUN/ST
OP Switch Operation
in
Chapter 4
.
The
Reset
pushbutt
on,
located just
above
these switches,
is currently not
used.
RDSD Switch Operation CPE330
RDSD Pushbutto
ns
Function
RDSD UPLD
Loads user program
or data from CPU to RDSD.
RDSD DNLD
Stores user pr
ogram or data
from RDSD to CPU.
Refer to
Removab
le Data S
torage Devices (
RDSDs)
for full descript
ion of RDSD fu
nctionality.
73
75
