Appendix A. Performance Data
GFK-2222AD April 2018 263
A-2.3 RX3i & RSTi-EP Instruction Times
The following tables are intended to provide guidance for expected instruction execution times when
using Ladder Diagram (LD) and C Language. For simplicity, the instructions are grouped as follows:
• Boolean Operation: this includes coil and contact operation (LD only).
• Word Operation: applies to MOVE instruction for all basic types.
• Fixed-point math covers all math operations which are not floating point (INT, UINT, DINT types).
• Floating-point math covers all math operations which are not fixed point (REAL and LREAL types).
