A-3.3 Programmer Sweep Impact Times
The following table shows nominal programmer sweep impact times in microseconds (µs).
Sweep Impact Item
RX3i
RX7i
RSTi-EP
CPU310
(µs)
CPU315
CPU320
CRU320
(µs)
CPE330
CPE400
(µs)
CPE010
(µs)
CPE020
CRE020
(µs)
CPE030
CRE030
(µs)
CPE040
CRE0400
(µs)
CPE100
CPE115
(µs)
Programmer window
2.90
0.20
1.46
1.95
0.21
0.20
0.20
Not determined
Reference table monitor
4.90
0.29
1.48
1.20
0.33
0.26
0.29
Not determined
Editor monitor
4.10
0.31
1.41
1.41
0.35
0.31
0.31
Not determined
Definitions:
Programmer
window
The time required to open the Programmer Window but not process any requests.
The programmer is attached through an Ethernet connection; no reference values are
being monitored.
Reference
table monitor
The sweep impact to refresh the reference table screen. (The %R table was used as
the example.) Mixed table display impacts are slightly larger. The sweep impact may
not be continuous, depending on the sweep time of the CPU and the speed of the host
of the programming software.
Editor monitor
The sweep impact to refresh the editor screen when monitoring ladder logic. The
times given in the table are for a logic screen containing one contact, two coils, and
eleven registers. As with the reference table sweep impact, the impact may not be
continuous.
