Chapter 2
.
CPU Features
& Specifications
GFK
-2222AD
April 2018
55
Display Port
The Display port is n
ot functional at tim
e of publicat
ion.
The
Display
Po
rt
is
a
DP++
video
port
located
on
the
underside
of
the
CPE440
(Figure
3).
It
provides
signals
for connecting a
suitable monitor or vid
eo adapter. Pin
outs for the Display
Port (Figure
14
) a
re:
Pins
Signal Name
1/3
TxD0+/-
4/6
TxD1+/-
7/9
TxD2+/-
10/12
TxD3+/-
13
AUXSEL
15
CLK/AUX+
17
DAT/AUX-
18
HTPLG
14
NC
20
DP_VCC
43
2, 5, 8, 11, 16, 19
GND
Figure
14
: Displa
y Port Connector
43
DP_VCC is limited to 720mA by an electron
ic fuse.
However, for normal operation do not exceed 500mA at this pin.
65
67
