Chapter 6. Serial I/O, SNP & RTU Protocols

220 PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual GFK-2222AD

Sample Autodial Command Block

This COMMREQ command block dials the number 234-5678 using a Hayes-compatible modem.

Word

Definition

Values

0009h

CUSTOM data block length (includes command string)

0000h

NOWAIT mode

0008h

Status word memory type (%R)

0000h

Status word address minus 1 (Register 1)

0000h

not used

0000h

not used

04400 (1130h)

Autodial command number

00030 (001Eh)

Modem response timeout (30 seconds)

0012 (000Ch)

Number of bytes in command string

5441h

A (41h), T (54h)

5444h

D (44h), T (54h)

3332h

Phone number: 2 (32h), 3 (33h)

3534h

4 (34h), 5 (35h)

3736h

6 (36h), 7 (37h)

0D38h

8 (38h) <CR> (0Dh)
