Appendix A
.
Performance
Data
274
PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual
GFK
-2222AD
Instruction
CPE010
(µs)
CPE020
(µs)
CRE020
(µs)
CPE030/
CRE030
(µs)
CPE040/
CRE040
(µs)
LIFOWRT_DWORD
0.00101
0.00029
0.00028
0.00020
0.00007
Array
ARRAY_MOVE_BIT
0.01967
0.00841
0.00863
0.00914
0.00304
ARRAY_MOVE_BYTE
0.00957
0.00387
0.00379
0.00358
0.00119
ARRAY_MOVE_INT
0.02002
0.00857
0.00857
0.00670
0.00223
ARRAY_MOVE_DINT
0.04762
0.02019
0.02021
0.01640
0.00547
ARRAY_MOVE_WORD
0.02063
0.00883
0.00878
0.00643
0.00211
ARRAY_MOVE_DWORD
0.04489
0.01922
0.01913
0.01529
0.00511
ARRAY_MOVE_UINT
0.02014
0.00863
0.00922
0.00687
0.00231
SRCH_BYTE
0.07277
0.03143
0.03112
0.03001
0.01010
SRCH_WORD
0.07492
0.03186
0.03177
0.02826
0.00940
SRCH_DWORD
0.06664
0.02854
0.02841
0.02641
0.00882
ARRAY_RANGE_DINT
0.54220
0.23200
0.23221
0.23434
0.07808
ARRAY_RANGE_INT
0.51968
0.22242
0.22204
0.22419
0.07467
ARRAY_RANGE_UINT
0.51902
0.22204
0.22200
0.22429
0.07492
ARRAY_RANGE_WORD
0.52001
0.22294
0.22249
0.22550
0.07511
ARRAY_RANGE_DWORD
0.55802
0.23898
0.23903
0.23764
0.07917
284
286
