Appendix A. Performance Data
GFK-2222AD April 2018 291
Example Calculation for EGD Utilization on RX3i CPE302/CPE305/CPE310 and RSTi-EP
CPE100/CPE115
The watchdog time configured to 200ms for calculations in the table below:
Normal Sweep – EGD on RX3i CPE302/CPE305/CPE310 and RSTi-EP CPE100/CPE115 Embedded
Ethernet Interface
The following table shows the chart for setting up EGD exchanges on Embedded Ethernet for RX3i
CPE302/CPE305/CPE310 with a no sweep load and no network traffic. The table is a compilation of
results based on testing with two RX3i CPE310 Systems in which one is acting as the EGD Producer and
the other is acting as the EGD Consumer.
SN EGD Exchange Type of Exchange Period Total_EgdImpactPerWDT_ms[n]
1 EGD Exchange#1 Producer 25 1.600
2 EGD Exchange#2 Producer 25 1.600
3 EGD Exchange#3 Producer 30 1.333
4 EGD Exchange#4 Producer 30 1.333
5 EGD Exchange#5 Consumer 30 1.333
6 EGD Exchange#6 Consumer 50 0.800
7 EGD Exchange#7 Consumer 50 0.800
8 EGD Exchange#8 Consumer 50 0.800
9.600
4.800
