Chapter 2
.
CPU Features
& Specificatio
ns
86
PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual
GFK
-2222AD
CPE010
CPE020
CPE030
CPE040
Communications
10BaseT/100BaseT RJ45
10BaseT/100BaseT
x2
10BaseT/100BaseT
x2
10BaseT/100BaseT
x2
10BaseT/100BaseT
x2
Advanced User Parameters (AUP file) config
Y
Y
Y
Y
RS
-232
9-pin D-conn x1
9-pin D-conn x1
9-pin D-conn x1
9-pin D-conn x1
RS
-485
15-pin D-conn x1
15-pin D-conn x1
15-pin D-conn x1
15-pin D-conn
x1
Station Manager Port (dedicated
RS
-232)
51
9-pin D-conn x1
9-pin D-conn x1
9-pin D-conn x1
9-pin D-conn x1
Protocols
Modbus RTU Slave
Y
Y
Y
Y
SNP Slave
Y
Y
Y
Y
Serial I/O
Y
Y
Y
Y
SRTP (# simultaneous server connections)
up to 16
up to 16
up
to 16
up to 16
Web-server (http) and FTP connections
up to 16
up to 16
up to 16
up to 16
Ethernet Global Data (EGD)
33
Y
Y
Y
Y
Number of EGD Exchanges (max)
34
255
255
255
255
Selective Consumption of EGD
Y
Y
Y
Y
Remote Station Manager over UDP
Y
Y
Y
Y
Station Manager over Serial Comm Port
Y
Y
Y
Y
51
[Optional] Serial Port cable
:
IC200CBL001
96
98
